| Part NO. | Thread | Hose | Tube OD | O-Ring | Dimension (mm) | ||
| DN | Dash | C | S2 | ||||
| 20491-12-03 | M12X1.5 | 5 | 03 | 6 | O04.5X1.5 | 1 | 17 |
| 20491-12-04 | M12X1.5 | 6 | 04 | 6 | O04.5X1.5 | 1 | 17 |
| 20491-14-04 | M14X1.5 | 6 | 04 | 8 | O06.5X1.5 | 2 | 19 |
| 20491-16-04 | M16X1.5 | 6 | 04 | 10 | O08.0X1.5 | 2 | 22 |
| 20491-16-05 | M16X1.5 | 8 | 05 | 10 | O08.0X1.5 | 2 | 22 |
| 20491-16-06 | M16X1.5 | 10 | 06 | 10 | O08.0X1.5 | 2 | 22 |
| 20491-18-05T | M18X1.5 | 8 | 05 | 12 | O10.0X1.5 | 1.5 | 22 |
| 20491-18-06 | M18X1.5 | 10 | 06 | 12 | O10.0X1.5 | 2.5 | 24 |
| 20491-22-06T | M22X1.5 | 10 | 06 | 15 | O12.0X2.0 | 3 | 27 |
| 20491-22-08 | M22X1.5 | 12 | 08 | 15 | O12.0X2.0 | 2.5 | 27 |
| 20491-26-08T | M26X1.5 | 12 | 08 | 18 | O15.0X2.0 | 2.1 | 32 |
| 20491-26-10 | M26X1.5 | 16 | 10 | 18 | O15.0X2.0 | 2.5 | 32 |
| 20491-26-12 | M26X1.5 | 20 | 12 | 18 | O15.0X2.0 | 2.5 | 32 |
| 20491-30-10T | M30X2 | 16 | 10 | 22 | O20.0X2.0 | 3.8 | 36 |
| 20491-30-12 | M30X2 | 20 | 12 | 22 | O20.0X2.0 | 4 | 36 |
| 20491-36-12T | M36X2 | 20 | 12 | 28 | O26.0X2.0 | 4.5 | 46 |
| 20491-36-14T | M36X2 | 22 | 14 | 22 | O26.0X2.0 | 4.5 | 46 |
| 20491-45-16T | M45X2 | 25 | 16 | 25 | O32.0X2.5 | 4 | 55 |
| 20491-45-20T | M45X2 | 32 | 20 | 25 | O32.0X2.5 | 4 | 55 |
| 20491-52-20T | M52X2 | 32 | 20 | 42 | O38.0X2.5 | 4 | 60 |
| 20491-52-24T | M52X2 | 40 | 24 | 42 | O38.0X2.5 | 4 | 60 |
