JIC Hose 12611, Two-Piece Coupling For Hydraulic Applications In Steel

JIC Hose Fitting

The JIC Hose 12611 is a highly reliable two-piece coupling specifically designed for hydraulic applications in steel industries. This coupling provides a secure and efficient connection for hydraulic hoses, ensuring smooth and reliable fluid transmission. It is manufactured with utmost precision and crafted using high-quality materials to deliver exceptional durability and performance.
The JIC Hose 12611 features a unique design that enables seamless integration with hydraulic hoses. With its standardized JIC (Joint Industry Council) specifications, this coupling ensures compatibility with a wide range of hydraulic systems. The two-piece construction facilitates easy installation and maintenance, allowing for quick and hassle-free hose connections.
This coupling is specially engineered to withstand the demanding conditions of steel applications. It excels in high-pressure environments and effectively resists corrosion, ensuring long-lasting performance even in harsh operating conditions. Its robust construction provides optimal strength and durability, making it an ideal choice for hydraulic systems in steel industries.
The JIC Hose 12611 meets the stringent quality standards and industry regulations to deliver reliable and safe performance. It is designed to handle hydraulic fluid transmission with efficiency, precision, and minimal leakage. This coupling enhances the overall efficiency of hydraulic systems, enabling seamless operation and reducing downtime.
Contact Us
  • Specifications
  • Leave Us A Message
  • Part NO. Thread Hose Dimension (mm)
    DN Dash A C S1
    12611-02-03 G1/8"X28 5 03 22 10 12
    12611-04-04 G1/4"X19 6 04 24.5 12 14
    12611-06-05 G3/8"X19 8 05 26 13.5 17
    12611-06-06 G3/8"X19 10 06 27.5 13.5 17
    12611-06-08 G3/8"X19 12 08 26.5 13.5 19
    12611-08-06 G1/2"X14 10 06 30.5 16 22
    12611-08-08 G1/2"X14 12 08 31 16 22
    12611-10-08  G5/8"X14 12 08 32.5 17.5 24
    12611-10-10 G5/8"X14 16 010 33.5 17.5 24
    12611-12-08 G3/4"X14 12 08 35.5 18.5 27
    12611-12-10 G3/4"X14 16 10 37 18.5 27
    12611-12-12 G3/4"X14 20 12 36.5 18.5 27
    12611-16-12 G1"X11, 20 12 40.5 20.5 36
    12611-16-16 G1"X11 25 16 41.5 20.5 36
    12611-20-16 G1.1/4X11 25 16 43.5 20.5 46
    12611-20-20 G1.1/4X11 32 20 44.5 20.5 46
    12611-24-20 G1.1/2"X11 32 20 49 23 50
    12611-24-24 G1.1/2"X11 40 24 46 23 50
    12611-32-32 G2"X11 50 32 53.5 25.5 65
    Note:1、For braided hoses. 2、If for spiral hoses,Part No. is H12212-XX-XX.
